Max. one second measurement time.
Compact thermal printer is built in.
BR-5200P does not need a lamp replacement thanks to the LED light source.
A sample gauge provided on the surface of BR-5200P, which indicates the proper sample volume to be inspected.
Only simple action is required to set the capillary tube into the holder.
BR-5200P foot print is small and weights only 1.7 kg.
The dual wavelength measuring method of BR-5200P eliminates interference of hemolysis and turbidity.
BR-5200P has a USB interface for connection with computer.
Once BR-5200P is calibrated, no more daily calibration is required.
Method |
Dual Wavelength (461 and 577 nm) |
Measurement Range |
0 - 30 mg/dL(Total bilirubin) |
Correcting hemolysis |
0 - 250 m/dL |
Measuring accuracy |
±5 % |
Sample Volume |
50 - 60 μL |
Display |
3 1/2 LCD display |
Sample Container |
Hematocrit capillary tube |
Light source |
High bright LED |
Detector |
High sensitivite silicon photocell |
Interface |
USB |
Power |
100-240 VAC 50/60 Hz AC adapter |
Dimensions |
262 (W) X 214 (D) X 109 (H) mm |
Weight |
Around 1.7 kg (main body) |
Standard solution(ABY) |
2 bottles |
Capillary tube(Heparinized, Red) |
1 vial(100 pcs) |
Capillary tube(Plain, Blue) |
1 vial(100 pcs) |
Clay sealer(Wax Plate) |
1 pc |
USB Cable |
1 pc |
PC software(CD-ROM) |
1 pc |
AC/DC power code |
1 pc |
Operation manual |
1 copy |
Thermal paper roll |
1 roll |
*Specifications and appearance are subject to change without notice.
For more detail: http://www.apel.co.jp/products/medical_device/br-5200p.html?lang=en
