Easy, intuitive operation and user-paced prompts enable first-time rescuers to act quickly and confidently to a sudden cardiac arrest emergency.
Specifications
Defibrillator
- Operations: Fully automatic
- Waveform: STAR® biphasic truncated exponential
- Therapy range: (J) 95J to 354J (adult)
- Fast shock feature: 5 energy protocols available
- Voice prompts: RescueCoach™ prompts provide user-paced instruction Text screen Displays rescue prompts and critical rescue information
- Audible alerts: Voice prompt, system alert
- Synchronized shock: Built-in automatic synchronization feature
- Pacemaker pulse detection: Yes
- Synchronized shock: Built-in automatic synchronization feature
- Pacemaker pulse detection: Yes
- Pediatric capability: Therapy range (VE) 22J to 82J, pediatric prompts
- Dual Language Latin American Spanish or French Canadian (optional)*
- Customizable: Voice prompt, CPR settings, and shock protocols via AED Manager
- CPR: Metronome for CPR compression rate
- Visible indicators: Rescue Ready®, battery, service, and pad status
- Warranty: 8 years
Physical/Environmental
- Dimensions (H × W × D): 3.4 in × 9.0 in × 11.8 in (9 cm × 23 cm × 30 cm)
- Weight: 5.7 lbs (2.6 kg), including battery and pads
- Dust/water resistance: IP55 (IEC 60529)
- Operating temperature: 32 °F to +122 °F (0 °C to 50 °C)
- Altitude: –1,253 ft (–382 m) to (15,073 ft) 4,594 m
- Drop: MIL-STD-810G, 516.6 (Procedure IV) for 1.22 m drop
- Shocks: MIL-STD-810G, 516.6 (Procedure 1)
- Vibration (sine and random): MIL-STD-810G, 514.6 (Procedure 1, Cat 24)
- EMI (radiated/immunity): IEC 60601-2-4
PADS Intellisense™ Defibrillation Pads
- Type: Disposable, non-polarized (pads can be placed in either position)
- Shelf life: 2 years
Battery
- Type: Intellisense® Lithium Battery
- Guarantee: 4-year, full operational replacement
- Capacity: 420 shocks (typical) at 300VE
Automatic Self-Tests
- Daily, weekly, and monthly: Electrical circuitry, AED software, medical grade battery and defibrillation pads (presence and function)
- Weekly: Includes partial energy charge
- Monthly: Includes full energy charge cycle
Event Documentation
- Internal memory: 90 minutes of rescue data, multiple rescue functionality
- ECG and rescue review: Viewable via AED Manager reporting and configuration software
- Communications: USB cable or USB memory stick
Always Rescue Ready®
Rest easy knowing your Powerheart AED will perform as expected during a rescue thanks to Rescue Ready technology that performs rigorous daily, weekly, and monthly self-tests. The Powerheart G5 also includes a medical-grade battery with a 4-year full operational guarantee, an 8-year warranty, and the best tools and support.
Take Out The Guesswork
During a tense rescue, both experienced and first-time rescuers will benefit from the Powerheart G5’s RescueCoach™ user-paced instruction, intuitive pad design, and automatic shock delivery to reduce the likelihood of human error. (Semi-automatic model also available.)
Cardiac Science Strong
Light enough to travel anywhere but strong enough to pass military standards and receive an IP55 rating for protection from dust and water, the Powerheart G5 is built to withstand the rigors of your job. Our latest innovation now features customizable escalating energy, faster shock times, and dual-language capability.
